1. Drexus Slot Drain Installation Kit

Slot Drain® is pre-sloped and fully assembled. It is easy to install, reducing labour costs and minimizing chances of error.

Slot drainage This is a term that is often incorrectly used referring the broad family of ‘Channel’ systems. While it is a ‘channel system’ with a surface element and an underlying channel component, it differs in that the surface interface is defined by a discrete slot as opposed to a grating. Install Similar to Standard Trench Drain Pre-Sloped Modular System. Slot Drain installs very similiar to standard trench drain systems. Bolt together, flanged system makes it easy to install. Remember: Sections are bolt together; Start at the catch basin and work backwards; Use the levelling arms to level the drain bodies.

• Drexus XL with reference numbers indicated in bold black are available ex-stock. Drexus XL with reference numbers indicated in light are manufactured to order. Contact our sales office to discuss your requrements. End Caps Unit Weight (kg) Item Code 325 End Cap 1 DR537910 425 End Cap 2.5 DR537920 525 End Cap 3 DR537930 675 End Cap 4.5 DR537940.
• The 65ARG40 is the narrowest standards approved model of modular linear grate drainage systems. It features a wedge wire, stainless steel grate, manufactured from 316 marine grade stainless steel, combined with a UPVC drainage channel.

Drain sections arrive fully assembled and ready to install — no grating to screw on, no anchors or drains to weld, simply bolt the drain ends together, then pour your floor.

It takes two people approximately 20 to 30 minutes to install one 15 foot section.

1) Excavate a trench allowing for room underneath and on both sides of Slot Drain®. There should be a minimum of 6″ of concrete surrounding the drain.

2) It is recommended to pre-pour a concrete pad underneath the Slot Drain® pit so it can be properly secured. If no pad is poured, peg the sump pit down (using the flat bar mounting brackets bolted to the sides of the sump and wooden stakes) before Slot Drain® is connected.

3) Install all Slot Drain® pits and piping, making sure that the Slot Drain® pit walls are reinforced to prevent sidewall bowing.

4) Bolt the last (deepest) section of Slot Drain® to the Slot Drain® pit. If a Slot Drain® pit is not being used, start at the deepest section. Bolt all remaining sections of Slot Drain® together using the numbered flanges as a guide. For example, if you have a section 102, a section 203, a section 304 and a Slot Drain® pit. First, bolt flange 4 of section 304 to the Slot Drain® pit side marked 4. Next, bolt flange 3 of section 304 to flange 3 of section 203. Finally, bolt flange 2 of section 203 to flange 2 of section 102. Use a continuous bead of silicone sealant between all bolted sections.

5) Use wooden stakes to set the desired elevation of drain sections. Secure drain sections to the stakes with the mounting holes provided on the levelling brackets.

6) Once Slot Drain® is secured and the appropriate elevation is achieved, for structural support, tie the rebar from the floor grid into the rebar/levelling bars on the drain assembly. Cover the opening with the duct tape, or insert Styrofoam if needed.

7) To ensure that Slot Drain® will not float, it is recommended that the concrete be poured in two stages. Once adequate time for the first concrete pour to set has elapsed, the floor slab can be completed. The use of a pencil vibrator is strongly recommended to make sure that the concrete has completely surrounded Slot Drain®, leaving no bubbles or voids.

8) Once the concrete slab is firm, first remove the tape or Styrofoam from the slot and then break out all metal tabs to ensure a continuous open slot. Using the paddle, clean out the Slot Drain®.

RETROFIT

Slot Drain® Systems arrives at the site in fully assembled sections and is ready to be installed.

1) Layout and mark drain location on existing slab.

2) Cut 24″ wide trench in existing slab.

3) Excavate the trench allowing for room underneath and on both sides of Slot Drain®.. There should be a minimum of 6″ of concrete surrounding the drain.

4) Drill and dowel into the sides of the existing cut slab. Approximately 16″– 24″ on both sides.

5) It is recommended to pre-pour a concrete pad underneath the Slot Drain® pit so it can be properly secured. If no pad is poured, peg the sump pit down (using the flat bar mounting brackets bolted to the sides of the sump and wooden stakes) before Slot Drain® is connected.

6) Install all Slot Drain® pits and piping, making sure that the Slot Drain® pit walls are reinforced to prevent sidewall bowing.

7) Bolt the last (deepest) section of Slot Drain® to the Slot Drain® pit. If a Slot Drain® pit is not being used, start at the deepest section. Bolt all remaining sections of Slot Drain® together using the numbered flanges as a guide. For example, if you have a section 102, a section 203, a section 304 and a Slot Drain® pit.

First, bolt flange 4 of section 304 to the Slot Drain® pit side marked 4. Next, bolt flange 3 of section 304 to flange 3 of section 203. Finally, bolt flange 2 of section 203 to flange 2 of section 102. Use a continuous bead of silicone sealant between all bolted sections.

8) Use wooden stakes to set the desired elevation of drain sections. Secure drain sections to the stakes with the mounting holes provided on the levelling brackets.

9) Once Slot Drain® is secured and the appropriate elevation is achieved, for structural support, tie the rebar from the dowels and floor grid into the rebar/levelling bars on the drain assembly. Cover the opening with the duct tape, or insert Styrofoam if needed.

10) To ensure that Slot Drain® will not float, it is recommended that the concrete be poured in two stages. Once adequate time for the first concrete pour to set has elapsed, the floor slab can be completed. The use of a pencil vibrator is strongly recommended to make sure that the concrete has completely surrounded Slot Drain®., leaving no bubbles or voids.

11) Once the concrete slab is firm, first remove the tape or Styrofoam from the slot and then break out all metal tabs to ensure a continuous open slot. Using the paddle, clean out the Slot Drain®.

Slot Drain has been installed successfully in hundreds of applications, satisfying customers and construction professionals alike.

Slot Drain is designed for numerous market sectors. Slot Drain is made to suit your special requirements. Slot Drain provides drainage solutions that are durable, sanitary, aesthetically appealing, easy to clean, load class rated, corrosion and temperature resistant, ADA Compliant and odour eliminating.

Before Slot Drain, grating, trench drains and four-sloped floors were the standards.

Drexus Slot Drain Installation Kit

Slot Drain changed surface drainage forever by providing the first pre-sloped, prefabricated drain system. The linear slot eliminates traditional grates that can be weak, trap bacteria and are difficult to clean. Slot Drain is applicable wherever floor or ground surfaces are subject to fluids, or have frequent cleaning requirements.
